1983 Vollmer Dornhan Finimat 4/800
Sold
1983 Vollmer Dornhan Finimat 4/800
Description
Suitable for the automatic grinding of tooth face and tooth back on carbide-tipped circular saw blades. Accessories: Wet grinding device´ Halogen machine light, 1 set of centering rings 1 used diamond grinding wheel 1 grinding wheel guard
Specifications
| Manufacturer | Vollmer Dornhan |
| Model | Finimat 4/800 |
| Year | 1983 |
| Condition | Used |
| Stock Number | M01473 |
| Circular saw blade diameter | 80 to 800 mm |
| Circular saw hole diameter | any with the appropriate accessories |
| Tooth pitch | 1 - 110 mm |
| Sheet thickness | up to 16 mm |
| Rake angle | motorized adjustable from -20 ° to + 45 ° |
| Clearance angle | motorized adjustable from 8 ° to 45 ° |
| Helix angle | 0 - 45 ° |
| Tooth height difference | continuously adjustable up to 1 mm |
| Grinding wheel diameter | 100 or 125 mm |
| Grinding wheel bore diameter | 25 mm |
| Connected load | approx. 1.5 kW (400 V / 50 Hz) |
| Weight | 650 kg |
| Dimensions W x D x H | 1650 x 1300 x 1960 mm |
| colour | green RAL 6011 |
