1994 Vollmer CHF 110
1994 Vollmer CHF 110
or
Call +49447192920
Description
Suitable for simultaneous, automatic grinding of both tooth flanks on carbide-tipped circular saw blades.
Accessories:
Motorized rake angle adjustment,
Coolant system,
Automatic central lubrication,
Machine light,
2 grinding wheel holders,
1 sawblade mounting bolt.
Specifications
| Manufacturer | Vollmer |
| Model | CHF 110 |
| Year | 1994 |
| Condition | Used |
| Stock Number | M02305 |
| sheet thickness | up to 8 mm |
| Tooth pitch | 6 to 120 mm |
| rake angle | - 15° to + 25° |
| Tangential free angle | 0° to 6° |
| Radial free angle | - 4° to +6° |
| Connection value | ca. 1,1 kW (400 V / 50 Hz) |
| Weight | about 1150 kg |
| Grinding wheel diameter | Max. 125 mm |
| Bore diameter | 32 mm |
| Dimensions L x W x H | 1340 x 1400 x 2000 mm |
| colour | green |
| Circular saw outer diameter | 80 to 460 mm |
